1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R

Ask Lasest Price
Brand Name :	Clirik
Supply Ability :	100 Set/Sets per Month
Price :	$15,890.00/sets 1-4 sets

Add to Cart

Product Details
Company Profile

1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R

1 Ton Per Hour Limestone Caco3 Mica Grinding Mill Powder Raymond Mill 4R Grinder 1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R

Product Description

YGM series Raymond roller mill is also called Raymond grinding
mill, Raymond pulverizer. YGM series Raymond roller mill is the new
type Raymond mill of our company, which is suitable for processing
various non-flammable and non-explosive mineral materials with
Moh's hardness less than 9.3 and humidity less than 6%.The main parts of Raymond roller mill is grinding roller, grinding
ring, grinding roller assembly, the plum flower frame, air
flue, coupling, perching knife and so on.

Technology Date of Raymond Mill

Note: This specification is just referencing, any changes are
subject to the products.

Model	Diameter(mm)	InputSize(mm)	FinalSize(mesh)	Host Power(KW)	Capacity(T/H)	Dimension <LWH>(mm)
YGM9720	970	20	80-600	97	1.5-7.5	820060107200
YGM1280	1280	20	80-600	145	2-10	850075008200
YGM1300	1300	20	80-400	222	2-14	1010093008330
YGM1620	1620	30	80-400	322	2.5-18	10250809010510
YGM1720	1720	35	80-325	442	6-30	125001225010400
YGM2150	2150	35	80-325	572	12-40	120001160011000

Raymond roller mill can be widely used in the fields of metallurgy,
construction, chemical industry, mining, highway construction etc,.
The granularity of the finished powder size can be adjusted between
30 and 425 mesh. Examples of processing materials include quartz,
feldspar, barite, calcite carbonate, limestone, talc, ceramic, iron
ore, carborundum, bauxite, rock phosphate, coal and other
materials, about 400 kinds of materials in total.

Working Principle of Raymond Mill

The working principle is as follows: load the stuff for grinding evenly and continuously into the grinding chamber of the main frame. Due to the centrifugal force in rotation, the roller swings go outward and presses closely upon the ring. The shovel carries the stuff to the space between the roller and ring. When the roller rolls, the stuff is thus grind. After being grind, the stuff is to be routed to the classifier along wind belt of the blower and the rough powder will be put back to the grinder for regrinding.

The fine powder flows into the cyclone collector together with air flow and is expelled from the powder output pipe as product. In the grinding chamber, since the stuff contains moisture to some extent, the heat generated during grinding makes the moisture evaporate; since the pipeline joints are not airtight, the external air is sucked in and the circulation air mass increases. In order to enable the grinder to work in negative pressure, the increased air flow is guided to the duster and sequentially to the atmosphere after purification.

Advantages of Raymond Mill

1. Higher output. Its output increases by 10%-20% comparing with Raymond mill under the same power condition.

2. Larger range of final fineness. Size of final product can be 0.613 mm (30 mesh) –0.033 mm (425 mesh). Some can reach the fineness of 0.013 mm (1000 mesh).

3.Good dust control. High Pressure Suspension Mill meets the requirement of national dust-dump standard.

4.Easy to operate. The whole system is combined by some independent systems, and the cohesion between the systems is good.

5. Excellent sealing. The multi-class seals are adopted to keep the grinding equipment tight closed.

Related Products---Raymond MillIf you are interested in our mining equipment, and want to know
more details about the stone powder production line project, you
are welcome to visit our---
Online Store

Ball Mill----------------------------------------------------------------
uniform powder size production

HGM Ultra Fine Mill----------------------------------------------------------------
150-3000 mesh powder processing

Jaw Crusher----------------------------------------------------------------
And other stone crushing machine

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Certifications

Packing & Delivery

Company Profile

SHANGHAI CLIRIK MACHINERY CO., LTD located in PUDONG New district
of Shanghai china as a pioneer enterprise, which is specializing in
research, manufacture and sales of all kinds of mining equipment.
Our company has already formed a full set of modern production
line, equipped with intelligent, standardized testing and
controlling laboratories, owned a professional team for R&D,
production, sales and service. So far, we have established a whole
production chain, the products cover micro powder grinding mill,
high pressure grinding mill, European version coarse grinding mill,
hammer crusher, jaw crusher, screw conveyor, bucket elevator and so
on. They are widely used in the industry of mining, construction
materials, chemicals, metallurgy, transportation, hydraulic
engineering and so on. Specially we independently developed HGM
micro powder grinding mill, which are not only renowned in domestic
market, but also have been sold widely in Eastern Europe, Middle
East, Africa, South Asia, Southeast Asia, Oceania, and America,
etc. We still insist on the communication and cooperation with
prestigious scientific research institutions from both home and
abroad to make our development ability always is in the domestic
front. Based on the principle of constant innovation and quality
guarantee, customer foremost, we are able to provide our customers
not only the highest quality products at the most favorable price
but also the most reasonable solution, such as the selection of the
equipment, optimized process configuration and a full range of
technical support, therefore we always follow your steps, pursue
your value and achieve your benefit.

Exhibition

Customer Photos

Customer Site on the World

So far, we have established a whole production chain, the products cover micro powder grinding mill, high pressure grinding mill,
European version coarse grinding mill, hammer crusher, jaw crusher, screw conveyor, bucket elevator and so on. They are widely
used in the industry of mining, construction materials, chemicals, metallurgy, transportation, hydraulic engineering and so on.
Specially we independently developed HGM micro powder grinding mill, which are not only renowned in domestic market, but also have
been sold widely in Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, and America, etc.
